The Blue Oval hit a proverbial home run with the release of the Ford 5.0L Coyote V8 back in 2011, largely thanks to its mix of performance, efficiency, and reliability. That winning combo (and iconic 5.0L displacement) was obviously a good fit the Mustang—but the Ford 5.0L Coyote engine was equally at home under the hood for the Ford F-150 pickup truck.
Yet there’s always room for improvement. So in 2015, Ford engineers made some key updates to the Coyote—for both the Mustang and F-150 engine versions. (If you didn’t know, there are some key distinctions between the Coyote engines found in the Mustang and F-150, most notably the truck motor’s Flex Fuel/E85 compatibility).
So that’s what we’re talking about here, the second-gen Ford 5.0L Coyote V8 for the F-150 offered from 2015 to 2017.
Click the links below to learn about the other engines in the Ford 5.0L Coyote family.
- 2011-14 Ford Mustang GT 5.0L First-Gen Coyote Engine Spec Guide
- 2015-17 Ford Mustang GT 5.0L Second-Gen Coyote Engine Spec Guide
- 2018-23 Ford Mustang GT 5.0L Third-Gen Coyote Engine Spec Guide
- 2012-13 Ford Mustang Boss 302 “Road Runner” Engine Spec Guide
- 2011-14 Ford F-150 5.0L First-Gen Coyote Truck Engine Spec Guide
- 2015-17 Ford F-150 5.0L Second-Gen Coyote Truck Engine Spec Guide
- 2018-23 Ford F-150 5.0L Third-Gen Coyote Truck Engine Spec Guide
First though, special thanks to the Summit Racing tech team and John Jones, Gary Vicich, and Matt Strebler for putting all of this Coyote engine spec data together in one place.
***
2015-17 Ford F-150 5.0L Second-Gen Coyote Truck Engine Spec Guide
***
| 2015-17 Ford F-150 5.0L Second-Gen Coyote Truck Engine Performance Specs | |
|---|---|
| Compression Ratio | 10.5:1 |
| Horsepower Rating | 360 hp |
| Torque Rating | 380 ft.-lbs. |
| 2015-17 Ford F-150 5.0L Second-Gen Coyote Truck Engine Application & VIN ID | |
|---|---|
| VIN 8th Digit | F |
| Years | 2015-18 |
| Make | Ford |
| Model | F-150 |
| 2015-17 Ford F-150 5.0L Second-Gen Coyote Truck Engine Block Specs | |
|---|---|
| Casting Numbers | FR3E-6006/6015 |
| Material | Aluminum, Steel Sleeve |
| Displacement | 5.0L (302ci) |
| Bore Diameter | 3.630 in. |
| Stroke | 3.650 in |
| Deck Height | 8.937 in. |
| Bore Spacing | 3.937 in. |
| Thrust Bearing Location | #5 Main |
| Main Cap Style | 4 Bolts with 2 Lateral Cross-Bolts (All 5 Mains) |
| Main Housing Bore Dia. | 2.851 in. |
| 2015-17 Ford F-150 5.0L Second-Gen Coyote Truck Rotating Assembly Specs | |
|---|---|
| Piston Material | Hypereutectic Cast Aluminum Alloy |
| Piston Style | Domed, Valve Reliefs |
| Piston Volume | 4.451cc |
| Wrist Pin Diameter | 0.865 in. |
| Connecting Rod Material | Sinter Forged |
| Connecting Rod Style | I-Beam |
| Connecting Rod Length | 5.933 in. |
| Connecting Rod Weight | 618 grams |
| Crankshaft Material | Forged Steel |
| Crankshaft Casting Number | BR3E-XXXX |
| Crankshaft Main Journal Dia. | 2.657 in. |
| Crankshaft Rod Journal Dia. | 2.086 in. |
| Oil Squirters | Yes |
| 2015-17 Ford F-150 5.0L Second-Gen Coyote Truck Cylinder Head Specs | |
|---|---|
| Casting Numbers | M-6050-M50 (Left) M-6049-M50 (Right) |
| Material | As Cast Aluminum AL319 |
| Combustion Chamber Volume | 57.5cc |
| Intake Port Shape | Oval with Dimple |
| Intake Runner Volume | 200cc |
| Exhaust Port Shape | Round |
| Exhaust Runner Volume | 104cc |
| Intake Valve Diameter | 1.468 in. |
| Exhaust Valve Diameter | 1.252 in. |
| Cylinder Head Bolt Style | Torque to Yield (TTY) |
| Cylinder Head Bolt Size | 12mm x 1.75 (10) |
| 2015-17 Ford F-150 5.0L Second-Gen Coyote Truck Camshaft Specs | |
|---|---|
| Duration @ .050 in. | 260° (Intake) 263° (Exhaust) |
| Valve Lift | 0.511 in. (Intake) 0.511 in. (Exhaust) |
| Lobe Separation Angle (LSA) | 116° |
| Cam Gear Attachment | 1 Bolt |
| Twin Independent Variable Cam Timing (Ti-VCT) | Yes |
| 2015-17 Ford F-150 5.0L Second-Gen Coyote Truck Valvetrain Specs | |
|---|---|
| Valve Spring Style | Beehive |
| Intake Valve Material | Steel, Solid Stem |
| Intake Valve Diameter | 1.468 in. |
| Exhaust Valve Material | Steel, Solid Stem |
| Exhaust Valve Diameter | 1.252 in. |
| Other Key 2015-17 Ford F-150 5.0L Second-Gen Coyote Truck Engine Specs | |
|---|---|
| Intake Manifold | Black Composite, With Charge Motion Valve |
| Throttle Body | 80mm |
| Throttle Control | Electronic |
| Fuel Injector Part Number | BR3Z9F593A |
| Fuel Injector Flow | 34 lbs./hr. @ 58 psi |
| Flex Fuel/E85 Capable | Yes |
| Fuel Injector Length | 1.900 in. Between O-Rings |
| Fuel Injector Connector | USCAR / EV6 |
| High Pressure Fuel Pump | No |
| Camshaft Sensor Location | Timing Cover |
| Oil Pan | Steel, 7.75 Quarts, Rear Sump |
| Oil Pump | Gerotor |
| Firing Order | 1-3-7-2-6-5-4-8 |
| Redline | 7,000 RPM |
